Sr. No. |
Specifications |
Details |
|---|---|---|
1 |
Loading Capacity - (KN) |
1000 |
2 |
Load accuracy |
+ 1% from 2% to 100% of Machine capacity |
3 |
Range(KN) |
20-1000 |
4 |
Load Resolution (KN) |
0.05 |
5 |
Resolution of Piston(mm) |
0.1 |
6 |
Max clearance for compression (mm) |
0-850 |
7 |
Max clearance for tension at fully descended piston (mm) |
50-850 |
8 |
Distance between columns(mm) |
850 |
9 |
Piston stroke (mm) |
220 |
10 |
Loading rate (KN/mm) |
0-80 |
11 |
Straining rate ( mm/min max) |
45 |
12 |
Standard accessories
a) Round Jaws b) Flat jaws |
10-25,25-45,45-70 0-2.2,22 -44,44-65 |
13 |
For Compration Test (mm) Pair of compration plates |
120 |
14 |
For Transverse Test Table with adjustable rollers
a) Width of rollers(mm) b)Dia of rollers (mm) c) Maximum clearance between supports (mm) d) Radius of Punch Tops (mm) |
160 50 800 16, 22 |
15 |
Connected Load |
5HP, 400 -440V, 3 phase |
16 |
LX W X H (Approx) (mm) |
2500 X 875 X 3175 |
17 |
Weight (Approx) (Kg) |
5500 |
